Photoelectric Cylindrical sensors FL Series

Datasensing FL Series

The FL Series delivers reliable long-range photoelectric detection in a rugged M18 “T-style” form-factor engineered for challenging industrial and outdoor environments. With models supporting through-beam sensing distances up to ~30 m, and a housing rated for high-pressure wash-down (IP69K), this series offers extended reach, robust durability, and fast, trustworthy detection in demanding automation systems.

Design & Functionality

• The series adopts a through-beam principle, comprising emitter and receiver pairs, to enable very long sensing distances (for example ~30 m) and stable detection of large or distant objects.
• The “T-style” M18 optical head housing is built from PBT + PC with stainless-type finish, and is designed for industrial installations including car-washes and outdoor conveyors.
• Wide voltage range (~19.2 … 28.8 V DC) and integrated protections – reverse-polarity, short-circuit, impulsive over-voltage – ensure industrial-grade reliability in harsh environments.
• LED indicators for RUN and output status allow quick visual diagnostics of the sensor pair in installation and maintenance phases.

Total Crossed Beams

(In this photo-electric context, this term refers to the full beam path between emitter and receiver remaining effective across long distances.)

• With the FL Series, the through-beam design ensures a clear uninterrupted detection path even at distances of tens of metres, reducing the risk of missed detection due to ambient light or mechanical interference.
• This leads to high detection reliability in long-span conveyor lines or wash-down zones where standard sensors might struggle.

Beam Pitch Options

(Here interpreted as selectable sensing-distance variants rather than literal beam spacing.)

• Standard models achieve a nominal sensing distance of around ~8 m (for emitter/receiver setups) for standard installations.
• High-distance variants reach up to ~30 m nominal sensing distance, suitable for large-scale conveyor or outdoor detection tasks.
• These options allow selection based on required span, target size/reflection and installation environment—offering flexibility in system design.

Intrinsic Synchronism

• The electronics in emitter and receiver are internally timed and matched—no external synchronisation wiring is needed—simplifying installation over long distances.
• The time before availability (startup delay) is ≤ 200 ms, meaning the sensor pair is ready quickly for production use.

Operational Advantages

• Extended Sensing Range: With up to ~30 m sensing distance in through-beam models, the FL Series covers large-scale detection needs in conveyors, outdoor systems or long spans.
• Industrial Durability: With IP67/IP69K rating, robust “T-style” M18 packaging and full protective electronics, the sensor thrives in harsh wash-down, dusty, aqueous or outdoor environments.
• Reliable Long-Span Detection: The through-beam design ensures clear detection path and stable operation at large distances—reducing false positives and missed detection in high-throughput setups.
• Applications: Ideal for car-wash detection systems, large conveyor installations, outdoor automation lines, pallet handling systems, packaging transfer zones and any environment where very long-range object detection, industrial protection, and simple installation are required.
