Datasensing Reflectors RL Series

Datasensing RL Series

The RL Series provides a robust family of reflector modules engineered for optimized retro-reflection sensing, long-distance detection capabilities, and flexible mounting formats. With options ranging from small 6-mm diameter reflectors to large panel reflectors up to 90 × 200 cm, and versions optimised for polarized sensors, this series delivers exceptionally strong signal return, enhanced reliability, and adaptability for varied machine layouts.

Design & Functionality

• The reflectors feature high-performance retro-reflective materials, designed for use with retro-reflection or polarized-retro-reflection sensor heads.
• Key characteristics include:
  • Polarized versions available, enabling improved immunity to ambient light and stray reflections, thereby increasing detection reliability.
  • Large format reflectors (for example up to 92 × 200 cm) available for long-range detection or wide sensing areas.
  • Compact sizes (Ø 6.5 mm up to ~42 mm width) for tight mounting spaces or low-clearance installations.
  • Mounting accessories (brackets, screws) and variants tailored for fixed mounting or conveyor-side detection applications.
• Mechanical details: The RL range supports simple installation, providing high reflectivity with minimal alignment requirements due to the retro-reflective design.

Important: The RL Series enhances the performance of retro-reflective sensors by providing maximum signal return, enabling far-side placement of the sensor and reducing installation constraints.

Total Crossed Beams

(Here interpreted as: full reflective coverage across the sensing path rather than literal optical beams crossing.)

• The RL Series ensures a stable reflective target surface, meaning that the sensor’s emitted beam is reliably returned to the receiver even if alignment shifts or if the target path varies slightly — leading to fewer missed detections, higher repeatability, and reduced maintenance.
• This stability is especially useful in production lines where parts pass through a portal or along a conveyor, and the sensor needs a consistent reflective surface to maintain performance.

Beam Pitch Options

(Here interpreted as variant options of reflector size, shape, and mounting format rather than literal beam spacing.)

• Example variant: Small cylindrical reflector for tight spaces (e.g., Ø 6.5 mm, suitable for compact sensors).
• Example variant: Medium panel reflector (e.g., 78.5 × 90 mm) for moderate coverage.
• Example variant: Large panel reflector (e.g., 92 × 200 cm) for long-range or wide area detection.
• These reflector format options allow you to choose an RL model that matches your sensor field geometry, installation clearance and detection distance — providing design flexibility.

Intrinsic Synchronism

• The reflector is passive but designed to pair seamlessly with the sensor’s emitter and receiver — no active electronics on the reflector itself — thus the sensor’s optics remain synchronised without additional components.
• With high-quality reflective materials and precise manufacturing, the RL series supports quick installation, low realignment, and stable long-term operation, reducing system downtime.

Operational Advantages

• Enhanced detection reliability: The high-return reflectivity and optional polarization increase signal margin and reduce false-triggering from ambient light or dust.
• Flexible installation geometry: With multiple sizes and formats from very small to large panels, the RL series adapts to new or retrofit installation scenarios.
• Cost-effective maintenance: Passive reflector modules require minimal upkeep, do not consume power, and maintain stability over time.
• Applications: Ideal for conveyor portals (object pass-through detection), long-distance photoelectric sensors up to tens of metres, packaging machine doors, robotics guard detection, material-handling gantries — anywhere retro-reflective sensing, high signal return, and simple mounting are required.
